DL-B1

Model: DL-B1-20B/ DL-B1-30B

Laser Model:MFP-20X/20QS / MFP-30X/30QS

Power:18.5/20W /30W

Beam Mass:≤1.4

Pulse Repetition Frequency:27 -60 kHz/30 -6 0 kHz

Laser Wavelength:1064±5 nm

Output Power Stability:1064nm

Output Power Stability: ＜3%

Design Life: Around 100000 working hour (non-serviceable)

Marking Range : 100~150mm(Range selectable)

Depth of Engraving: ≤1mm (Depends on power and time)

Engraving Speed:≤10000mm/s

Repeatability:±0.002

Minimum Marker Line Width:0. 1mm

Minimum character height:0.15mm

Cooling Methods:Built-in air-cooling

System Power Supply:500W / 220V / 50Hz(Can be connected with 110V)

Temperature and humidity:0~40°, 30%≤RH≤85%，Air conditioning is required for out-of-range use

Oil mist, Condensation:Not allowed

Operating System:Windows Operation System

File Formats:All fonts/typefaces of WINDOWS OS font library (standard USB input)

External Dimensions:460X300X683 mm

Packing Size:550X440X690 mm

Gross Weight:Around25kg
